12 Volt Bilge Pumps Automatic

Click here to view article on installing your bilge pump. This article contains important facts you should consider prior to your purchase.

​Please note, a bilge pump's sole use is for the intermittent pumping of seawater/freshwater ingress. Bilge pumps are not designed to pump chlorinated water, viscose liquids, oil or fuel.

Bilge Pumps are rated at "ZERO" head or height above outlet.

Also please note: GPH (LPH) and Maximum Head are always calculated in optimum test conditions. As a rule of thumb maximum head and GPH (LPH) should be calculated at 60% of the rated head and output.  This will ensure you are covered for both the run length and head height. For example; if you want an output of 1100GPH. Then fit a 2,000GPH bilge pump. A 4 metre rated maximum head is probably only effective to 2.4 metres with a horizontal run.

SPECIFICATIONS BY MODEL (12 Volt)

Model	LPM	Volts	Amps	Fuse (amps)	Hose Size (mm)	Base Dia (mm)	Dia inc Outlet (mm)	Height (mm)	Weight (Kgs)
750 GPH AUTO S6	43	12	5	5	19	83	145	103	0.47
1100 GPH AUTO S6	69	12	6	10	28.5	83	150	103	0.47
1100 GPH AUTO S11	69	12	5	5	28.5	83	166	103	0.55
1100 GPH AUTO S13	69	12	4	5	25 or 28.5	70	132	110	0.40
1100 GPH AUTO S14	69	12	4.2	5	19, 25 & 28.5	57	204	84	.56



Features & Benefits: Fully Automatic Silent and vibrationless operation Compact, efficient, long life motors Easy clean snap-lock strainer bases Anti-Airlock protection Exclusive moisture tight seals Completely submersible Marine grade blocked wiring Typical Applications: Marine and RV Liquid Temperature: 43°C Max Self Priming Does not need flooding for suction commencement Power: see above for max current draw per model   Motor: Type: compact, efficient, long life motor Leads: 18 AWG, 1 metre leads Temperature Limit: 43°C Maximum Duty Cycle: intermittent Voltage: 12 volts

(BILGE12VAUTO)
